Morcemcolor® Universal Grout CG2 A W

Additives and coloured mortar of mixed binders endowed with great fineness and plasticity. Suitable for sealing of joints from 2 to 15 mm in all kind of ceramic cladding. Especially suitable for low porosity pieces (ceramic tiles)

ISO-UNE-CG2-W-A ANSI 118.7 EN Adaptabilidad Todoterreno Casita_MuroIntExt_SueloIntExt

Download technical data sheet


Additional information

Composition

Product based on high resistance cement, aggregates, special additives, pigments and synthetic resins.

Features and applications

  • High hardness.
  • Intense colour.
  • Easy to clean.
  • Thin texture.
  • Low water absorption.
  • Resistant to cracks and abrasion.
  • Suitable for interior and exterior use.
  • Suitable for radiant heating.

Substrates

  • Empty joints should be dry and clean along their entire length and depth.
  • The grouting must be done 24 hours after gluing on vertical walls and 48 h. after flooring gluing.
  • Before starting the process, PROTECMOR, temporary filler protects porous and non-porous ceramics from possible pigment stains.

Instructions for use

  • Add water and mix manually or mechanically until getting a consistent homogeneous paste (make sure it is not very liquid)
  • Let the paste rest around 5 min. then mix again.
  • When working in small areas, fill the joints with the help of a rubber trowel or rechargeable pistol, compacting the material firmly.
  • The application should be done diagonally from the joints, pressing the mass on them and removing the excess material.
  • Allow the material to dry for approximately 20 or 30 minutes. When the paste becomes opaque, the surface can be cleaned with a slightly damp hard sponge.
  • Clean the surface with a clean and dry cloth, once the product in the joints has completely harden.
  • Let it dry for at least 24 h. before normal use.
  • If any of the tiles remain stained, use DESMOR to clean them, taking into account not to damage the tiles or the joints (see operating instructions of the product).

Cautions and recommendations

  • Do not apply the product under 5ºC nor above 40ºC temperature
  • Do not apply under the risk of frost, rain, heavy wind or direct sun light.
  • Do not use the product in expansion or subjected to structural movements of the work joints.
  • In the case of highly absorbent tiles or high temperatures, before filling the joints, moisten them with clean water, passing a damp sponge over them, avoiding the puddle of water inside.
  • Empty the joints completely before applying any product during restoration processes.
  • Do not clean the area with abundant water, or before the material is completely hard, in order to avoid carbonation and colour loss on the surface.

Consumption according to dimensions (kg/m²)

Yield (Kg/m²)
Data valid for 6 mm thick tiles

TILE SIZE
SEPARATION BETWEEN TILES
(JOINT SIZE)
2 mm 5 mm 8 mm 10 mm 15 mm
15 x 15 cm 0,27 0,68 1,09 1,36 2,04
15 x 20 cm 0,24 0,60 0,95 1,19 1,79
20 x 20 cm 0,20 0,51 0,82 1,02 1,63
25 x 33 cm 0,14 0,36 0,57 0,72 1,08
30 x 40 cm 0,12 0,30 0,48 0,60 0,89
40 x 60 cm 0,09 0,21 0,34 0,43 0,64
45 x 80 cm 0,07 0,18 0,28 0,35 0,53


((A+B)/AxB) x C x D x 0,17 = Kg/m²

Where:
A = Tile width 1 (cm)
B = Tile width 2 (cm)
C = Tile Thckness (mm)
D = Joint width (mm)

Packaging

5 Kg polyethylene bags.
Shelf life:
2 years (5 Kg polyethylene bags). In sealed original packaging, sheltered from weather conditions and humidity.

Colour range

Colour range:
The colours given are illustrative, there may be some variation due to technical limitations

Technical data

Statistical data obtained under standard conditions

Aspect White and range of colours
Resistence to flexion after 28 days > 2,5 N/mm² (EN 12808-3)
Resistence to compression after 28 days > 15 N/mm² (EN 12808-3)
Abrasion < 1000 mm³ (EN 12808-2)
Water absorption after 30 min. < 2 g (EN 12808-5)
Water absorption after 240 min. < 5 g (EN 12808-5)
UNE-EN 13888 Classification CG2 A W
ISO 13007 Classification CG2 A W
Complies with ANSI 118.7
Approximate yield See Table

Note

The instructions for use are given according to our tests and knowledge and do not imply any commitment by PidilitePuma Mea Chemicals LLC nor free the consumer from the examination and verification of the products for their correct use. Claims must be accompanied by the original packaging to allow a proper traceability.

PidilitePuma Mea Chemicals LLC is not responsible, in any case, for the application of its products or constructive solutions carried out by the application company or other parties involved in the process and / or execution of the work, limiting the responsibility of PidilitePuma Mea Chemicals LLC exclusively to the damages directly attributable to the supplied products, individually or integrated in systems, due to failures in their manufacturing process.

In any case, the drafter of the work project, the technical management or the person responsible for the work, or collaterally the application company or other parties involved in the process and / or execution of the work, must ensure the suitability of the products addressing the characteristics of them, as well as the conditions, support and possible pathologies of the work in question.

The values obtained by PidilitePuma Mea Chemicals LLC's products or its constructive solutions that, as the case may be, are determined by the EN standards or any other regulation that applies to it in each case refers exclusively to the conditions specifically stipulated in said regulation and that are referred to, among others, to certain characteristics of the support, humidity and temperature conditions, etc. without being them required in the tests obtained under different conditions, all in accordance with the relevant regulation.

Ranges

Colors in stock

Blanco 154
Amarillo 150
Flora 175
Hueso 183
Albero 174
Zafiro 152
Beige 172
Salmón 162
Plomo 186
Madera 182
Naranja 185
Gris Macael 157
Chocolate 164
Rubí 161
Gris 156
Terracota 163
Rojo 160
Negro 181
Wengé 184
Esmeralda 166
